Hanwha ANV-L6023R
Outdoor Vandal-Resistant Mini Dome 2MP, 3.6mm lens, IR, IK10

Request a quote

You will receive an offer for the following products
Hanwha ANV-L6023R
Outdoor Vandal-Resistant Mini Dome 2MP, 3.6mm lens, IR, IK10
Contact person:*
Company:*
Tel:Email:*
Message:*
Captcha:
Product details

Description Hanwha ANV-L6023R

Wisenet A-Series Mini Outdoor Vandalism Dome Camera, 2 MP @ 30 FPS, 3.6mm Fixed Focal Lens, FoV H: 94.8°/V: 49.3°, WiseStream II, Triple Codec (H. 265/H.264/MJPEG), 120 dB WDR, IR LEDs 15 m (49.21 ft), day and night (ICR), virtual area (intrusion/entry/exit), virtual line (intersection/direction), motion detection, tamper, corridor view, SD card, IP66, PoE, white.

Key Features:

  • 2 megapixel resolution (1920 x 1080).

  • 3.6mm lens with 94.8° HFoV

  • 30 fps at all resolutions (H.265/H.264)

  • H.265/H.264, MJPEG codec support, multiple streaming

  • Day and night (ICR), WDR (120dB)

  • Blur detection, direction detection, motion detection, entry/exit, tamper

  • Micro SD/SDHC memory slot (max. 32 GB), PoE

  • Hallway view, WiseStream II support

  • IR visible length 15m

  • IP66, IK10, NEMA4X support


Specifications

Product

Model numberANV-L6023R
GTIN code8801089228666
BrandHanwha
Category

IP Cameras

Dome

Camera Properties

Outdoor

Built-in infrared

Vandal resistant

Basic Functionality

Day and night

Local Storage

Resolution

1080p (2MP)

Hanwha Series

Wisenet A

Angle of View

91° - 100°

Encoding

H264

H265

MJPEG



Download
File name Filesize Filename extension Update date Download
DataSheet 316.79 KB pdf
User manual 2.58 MB pdf
Installation manual 2.05 MB pdf
Product dimensions 177.76 KB pdf
